Leaching tank

Usage and application :

Leaching agitation tank is a leaching equipment for cyanide leaching in gold CIP plant .The leaching tank is an important equipment for leaching. The volume of the leaching tank is generally 50-100m². At present, it tends to be large Large-scale tanks of 120~400m²have been used in industry. The leaching tank is divided into a mechanical stirring tank and an air stirring tank. The mechanical stirring tank uses the power to drive the propeller to stir the pulp, and the air stirring tank uses the compressed air to stir the pulp.

Working principle :

With dual impellers rotating and agitating, ore pulps move downward and then diffuse along with the damping plate. Air is fed in the tank from the lower end of the shaft and blended with ore pulps to form a uniform suspending mixed liquid.

In the gold cyaniding process, a leaching agitation tank is applied to leach and carbon-absorb ore pulps whose fineness is -200 meshes and whose density is less than 45%. Under similar circumstances, it is also applied to agitation and leaching in metallurgy, chemical, and light industry.

Features:

Ventilation, is surrounded by air to the bottom of the tube or hollow shaft ventilation, make the air through the air tube or hollow shaft into the mixing tank, uniform gas dispersion, small air bubbles.

The is a new type of rubber impeller in large diameter, rotational speed is low, long service life.

Have very strict control on the stirring intensity, make the concentration of the mixing tank and fineness is consistent with the

distribution. To improve the rate of pass in and out of cyanide and carbon adsorption rate.
